LED照明
LED照明
| 類型 | 型號 | 輸入電壓 | 典型應用 | 最大功率 | 電流 精度 | 效率 | 內置MOS | 調光方式 | 封裝 | 文件下載 |
|---|---|---|---|---|---|---|---|---|---|---|
| 超高壓線性 | TP8111 | 85V/265V | 260V/60mA | 18W | 5% | ＞85% | √ | SOT89-3 TO252-3 |  | |
| TP8121A | 85V/265V | 255V/45mA | 12W | 5% | ＞85% | √ | 三段開關 | ESOP8 | | |
| 隔離不帶PFC | TP8203 | 85V~265V | 10V/300mA | 1~4W | 5% | ≈80% | √ | SOP8 | | |
| 隔離帶 PFC | TP8302 | 85V~265V | 24V/300mA | 10~14W | 5% | ≈80% | √ | SOP8 | | |
| TP8311 | 85V~265V | 40V/300mA | 50W | 5% | ≈80% | PWM | SOP8 | | ||
| TP8321 | 85V~265V | 40V/300mA | 50W | 5% | ≈80% | 三段開關 | SOP8 | | ||
| 非隔離帶PFC | TP8601 | 85V~265V | 80V/300mA | 50W | 5% | ≈90% | SOT23-6 | | ||
| TP8602 | 85V~265V | 76V/220mA | 16~20W | 5% | ≈90% | √ | SOP7 | | ||
| TP8602D | 85V~265V | 80V/280mA | 22~26W | 5% | ≈90% | √ | DIP8 | | ||
| TP8611 | 85V~265V | 76V/350mA | 50W | 5% | ≈90% | PWM | SOP8 | | ||
| TP8621 | 85V~265V | 76V/300mA | 50W | 5% | ≈90% | 三段開關 | SOP8 | |
非隔離 不帶PFC | TP8533A | 85V~265V | 80V/200mA | 12~18W | 5% | ≈90% | √ | SOP7 | | |
| TP8533C | 85V~265V | 80V/240mA | 20~36W | 5% | ≈90% | √ | SOP7 | | ||
| TP8533F | 85V~265V | 120V/220mA | 19~34W | 5% | ≈90% | √ | SOP7 | | ||
| TP8533FD | 85V~265V | 120V/220mA | 20~36W | 5% | ≈90% | √ | DIP7 | | ||
| TP8553C | 85V~265V | 60v/240mA | 18~30W | 5% | ≈90% | √ | 三段開關 | SOP7 | | |
| TP8536D | 85V~265V | 165V/350mA | 60W | 5% | ≈90% | √ | DIP7 | | ||
| TP8561S | 85V~265V | 120V/220mA | 18~30W | 5% | ≈90% | √ | PWM | SOP7 | | |
| TP8562D | 85V~265V | 120V/220mA | 19~34W | 5% | ≈90% | √ | PWM | DIP7 | | |
| TP8563D | 85V~265V | 80V/240mA | 24~48W | 5% | ≈90% | √ | PWM | DIP7 | | |
| TP8564D | 85V~265V | 165V/350mA | 60W | 5% | ≈90% | √ | PWM | DIP7 | |
